Edge Computing Hardware Guide: Gateways, Industrial PCs, and Embedded Controllers

Edge computing brings processing closer to where data is generated — reducing latency, bandwidth costs, and cloud dependency. Here's how to choose edge computing hardware, from simple gateways to AI-capable industrial PCs.

Edge Hardware Tiers

Light Gateways: Protocol Translation + Basic Filtering

Best for: Modbus-to-MQTT bridging, basic data filtering, simple dashboards

Don't use for: Video processing, ML inference, heavy database workloads

Popular hardware:

• Raspberry Pi Compute Module 4 (industrial variant, -20°C to 85°C)
• STM32MP157 (Cortex-A7 + Cortex-M4, real-time capable)
• Mediatek Genio 350 (Yocto Linux, 10-year availability)

Mid-Range: Local Analytics + Dashboard

Best for: Video analytics (single camera), industrial protocol gateways, local HMI

Popular hardware:

• NXP i.MX 8M Plus (integrated 2.3 TOPS NPU)
• TI AM62x (Linux, industrial temperature, 10+ year availability)
• Rockchip RK3568 (quad Cortex-A55, NPU, under $30 in volume)

Chinese options:

• Rockchip RK3588 (quad A76 + quad A55, 6 TOPS NPU, 8K decode)
• Allwinner T527 (octa-core A55, 2 TOPS NPU, cost-optimized)

Performance Tier: AI Inference at the Edge

Best for: Multi-camera video analytics, defect detection, predictive maintenance

Popular hardware:

• NVIDIA Jetson Orin NX (70-100 TOPS, CUDA ecosystem)
• Hailo-8 M.2 module (26 TOPS, PCIe, pairs with any x86/ARM host)
• Google Coral M.2 (4 TOPS, TensorFlow Lite)

Industrial PCs: When You Need x86

Best for: Legacy Windows software, complex HMIs, factory floor integration

Key brands:

• Advantech (UNO, ARK, MIC series — wide temperature)
• Kontron (KBox series, railway certified)
• OnLogic (fanless, industrial, customizable)

Chinese IPC makers:

• EVOC (研祥) — China's largest IPC manufacturer
• Norco (华北工控) — Competitive pricing, wide range
• AAEON (研扬) — Asus subsidiary, good quality

Selection Checklist

1. Temperature range: 0-50°C (commercial) vs -40 to 85°C (industrial). Industrial-rated hardware costs 2-3x more.
2. Mounting: DIN rail for control cabinets, VESA for displays, wall-mount for gateways
3. I/O count: 2x Ethernet for network segmentation, isolated RS-485 for industrial protocols, CAN for vehicle interfaces
4. Certifications: CE/FCC for general use, EN 50155 for railway, ATEX for hazardous areas
5. Lifecycle: Industrial suppliers guarantee 7-15 year availability. Consumer-grade SBCs change every 1-2 years.
6. Power: 9-36V DC input for industrial/vehicle use. Don't rely on USB power in the field.

Sourcing Edge Hardware

• Single-board computers: Lead times have normalized (4-8 weeks for industrial variants). CM4 shortages (2021-2023) are resolved.
• NVIDIA Jetson: Orin series is in production; stock available through Arrow and Avnet.
• Custom carrier boards: For volume >1000 units, design your own carrier around a compute module. Costs $10-30K for design + $50-100/board at volume.
