How to Choose the Right Voltage Regulator

Voltage regulators are one of the most common components in any electronic design. Choosing the wrong one means re-spinning your PCB or dealing with heat issues in production. This guide covers the key decision factors and popular part numbers for each type.

Linear vs Switching: Which Do You Need?

Factor	Linear Regulator (LDO)	Switching Regulator (DC-DC)
Efficiency	30-60%	80-95%
Noise	< 100µV	10-100mV ripple
BOM Cost	Low ($0.10-0.50)	Higher ($0.50-3.00)
PCB Space	Small (3 pins)	Larger (inductor + caps)
Heat	More heat (Vin-Vout)×I	Less heat
Best For	Audio, RF, sensitive analog	Battery power, high current, high ∆V

Rule of thumb: If (Vin - Vout) × I > 0.5W, use a switching regulator. Below that, use an LDO.

Popular Linear Regulators (LDO)

Fixed Output

Part Number	Output	Current	Dropout	Package	Best For
AMS1117-3.3	3.3V	1A	1.2V	SOT-223	Most common 3.3V LDO
AMS1117-5.0	5.0V	1A	1.2V	SOT-223	5V LDO for MCUs
L78M05CDT	5.0V	500mA	2V	DPAK	Industrial 5V rail
LM1117MP-3.3	3.3V	800mA	1.2V	SOT-223	AMS1117 alternative
NCP1117ST33	3.3V	1A	1.2V	SOT-223	Onsemi quality
AP2112K-3.3	3.3V	600mA	250mV	SOT-23-5	Ultra-low dropout
HT7333	3.3V	250mA	40mV	TO-92	Ultra-low Iq (2.5µA)

Adjustable Output

Part Number	Output Range	Current	Famous For
LM317T	1.25V-37V	1.5A	The classic adjustable regulator
LM337T	-1.25V to -37V	1.5A	Negative complement to LM317
LM1117-ADJ	1.25V-13.8V	800mA	SMD adjustable regulator

Cost Comparison — LM317 Alternatives

Part Number	Price (1K)	Current	Notes
LM317T (TI)	$0.45	1.5A	Reference
LM317T (ST)	$0.35	1.5A	Drop-in equivalent
GW317	$0.12	1.5A	Chinese alternative, same specs
CW317	$0.10	1.5A	Chinese alternative

Popular Switching Regulators (DC-DC)

Step-Down (Buck) Converters

Part Number	Input	Output	Current	Frequency	Best For
LM2596S-ADJ	4.5-40V	1.25-37V	3A	150kHz	Classic through-hole module
LM2596S-5.0	4.5-40V	5V	3A	150kHz	Fixed 5V version
MP1584EN	4.5-28V	0.8-28V	3A	1.5MHz	Compact, higher frequency
TPS5430	5.5-36V	1.22V+	3A	500kHz	TI quality, enable pin
XL4015	8-36V	1.25-36V	5A	180kHz	High current
AP63203	3.8-32V	3.3V	2A	500kHz	SOT-23-6 tiny
FR9888	4.5-23V	0.925V+	3A	340kHz	MP1482 alternative

Step-Up (Boost) Converters

Part Number	Input	Output Max	Current	Best For
MT3608	2-24V	28V	2A	Small SOT-23-6 boost
XL6009	5-32V	60V	4A	High voltage boost
SX1308	2-24V	28V	2A	MT3608 alternative

Chinese DC-DC Alternatives (40-70% Savings)

Western Part	Chinese Alternative	Savings	Package
LM2596S	XL4015	~40%	TO-263-5
MP1584EN	FR9888	~50%	SOIC-8
MP2307DN	FR9886	~50%	SOIC-8
TPS5430	XL4015	~40%	TO-263-5
LT1936	MT3608	~70%	SOT-23-6

Selection Checklist

□ Determine required output voltage and current
□ Calculate power dissipation: (Vin - Vout) × Iout
□ If > 0.5W → switching regulator (buck/boost)
□ If < 0.5W → LDO (simpler, cheaper, quieter)
□ Choose package: heatsink (TO-220) or SMD (SOIC/SOT)
□ Check dropout voltage at max current
□ Verify enable/power-good features if needed
□ Order samples for thermal testing
