Optocoupler Selection Guide: Types, Parameters, and Alternatives
What is an Optocoupler?
An optocoupler (or optoisolator) transfers electrical signals between two isolated circuits using light. They're essential for safety isolation, ground loop elimination, and high-voltage switching.
Popular Optocoupler Comparison
| Part Number | Channels | Isolation | CTR | Output | Speed | Best For |
| PC817 | 1 | 5000Vrms | 50-600% | Transistor | 2µs | Power supply feedback, general isolation |
| TLP185 | 1 | 3750Vrms | 100-300% | Transistor | 3µs | Compact SOP-4, space-saving |
| TLP291 | 1-4 | 2500Vrms | 100-600% | Transistor | 3µs | Multi-channel isolation |
| 4N35 | 1 | 2500Vrms | 100% | Transistor | 10µs | Classic, hobby projects |
| MOC3021 | 1 | 7500Vpk | — | Triac | — | AC load / SSR trigger |
| MOC3063 | 1 | 7500Vpk | — | Triac ZC | — | Zero-cross AC switching |
| 6N137 | 1 | 2500Vrms | — | Logic | 75ns | High-speed digital isolation |
| EL357N | 1 | 3750Vrms | 200-400% | Transistor | 4µs | PC817 SMD alternative |
PC817 is the most popular optocoupler in the world — used in nearly every switching power supply.
Current Transfer Ratio (CTR) — Why It Matters
CTR = (output current) / (input current) × 100%
| CTR Grade | Range | Best For |
| Low (50-100%) | A/B grade | High LED drive available |
| Medium (100-200%) | C/D grade | Balanced, most common |
| High (200-600%) | GR/Y grade | Low LED drive, high load |
Important: CTR degrades over time and with temperature. Design with 20-30% margin.
Chinese Optocoupler Alternatives
| Western Part | Chinese Alternative | CTR Match | Savings |
| PC817 | EL357N (Everlight) | Same grades | 20-30% |
| PC817 | OC817 (Orient) | Same grades | 30-40% |
| TLP185 | EL185 (Everlight) | Similar | 30% |
| 4N35 | EL4N35 (Everlight) | Same | 40% |
| MOC3063 | EL3063 (Everlight) | Same | 30% |
Everlight (亿光) from Taiwan is the largest optocoupler manufacturer globally by volume. Their EL series is often cheaper than Japanese brands (Toshiba, Sharp) with comparable quality.
Selection by Application
| Application | Recommended | Why |
| Power supply feedback | PC817 / EL357N | Industry standard, widely available |
| Signal isolation (slow) | 4N35 | Enough speed for GPIO / sensor signals |
| Multi-channel isolation | TLP291-4 | 4 channels in one SOP-16 |
| AC switching | MOC3063 | Zero-cross detection built-in |
| Digital bus isolation | 6N137 | 10Mbaud, enough for SPI/UART |
| Industrial I/O modules | EL357N | SMD, cheap, compact |
